System structure: | Embedded Linux system, ARM chip structure |
Chip: | XM550 |
Video compression standard: | H.265/20FPS |
Connection method: | WIFI, AP hotspot , RJ45 Network port |
Network: | WIFI wireless transmission (support IEEE802.11b/g/n wireless protocol). |
Night vision | IR-CUT switch Automatic，about 5-8meters (It varies from environment) White Led can be remote control via APP:①Turn ON ②Turn OFF ③ Auto (In automatic mode, the infrared light will be turned ON after the IR-cut switch to night vision automatically , it can intelligently detected human body, and Turn ON/OFF the White light intelligently ) |
Audio: | Built-in microphone and speaker, support two-way audio and real-time transmission. ADPCM audio compression standard, self-adapt to code stream |
Network protocol: | TCP/IP、UDP、HTTP、 DDNS、DHCP、FTP、NTP |
Alarm: | ①Motion detection and picture push ②AI Human intrusion Detection (optional) |
ONVIF | Support ONVIF |
Storage: | TF Card（Max 128G）；Cloud storage /Cloud disk (optional) |
